Automatic Stretch Hood Wrapping Machine with High Efficiency
Description and electric powered brand
The complete computer is geared up with computerized swords threading system.
With the feature of auto tape threading.
The lifting of strapping heading is pushed via equipment motor SEW to make sure steady operation and dependable braking.
With the strapping head of mannequin VK10 K120-16 of TITAN Germany. The inside of each and every strapping is 15s.
The tape spool Model KE-400 is with the auto belt gathering function.
The PLC is SmartS7-200 manage gadget (SIEMENS). The patron can v set the instances and distance as per the requirement.
Technical data
Item | Specification |
Wrapping specifications | (500-1300)mm*(500-1200)mm. |
Packing height | 2400mm |
Packaging efficiency | 30-60 loads/H available. (Option: or 20-40 loads/H) |
Arm speed | 0-35rpm frequency control. (Option 15rpm, 25rpm) |
Arm performance | High sensitivity emergency brake system, the arm automatically reset. |
Film carriage system | Pre-stretch film carriage, stretch ratio up to 300%, automatic film feeding & cutting device, adjustable speed. |
Lifting column | Chain structure, speed variable frequency adjustable. |
Control system | PLC programmable control, wrapping layer adjustable, automatic height sense. |
Machine weight | 680KG (without support) |
Machine dimensions | 1300mmx1300mmx2000mm |
Power/ voltage | Arm 1.1/1.5kw, Film carriage 0.37kw, lift 0.37kw/0.55kw, conveyor 0.75kw/AC220V |
Option: Safety warning and protection fence, Photo-eye protection for infeed and outfeed goods (Conveyor line) | |
Automatic re-wrap and film break alarm
Alerts operator to rethread machine, and prevents unwrapped loads from passing through the system.
The headquartered of Shandong Sinolion Machinery Corp., Ltd (hereinafter short for Sinolion Machinery) is located in Jinan city, China. Sinolion Machinery is specialized in providing intelligent packaging solution, and is the subsidiary of Moon-tech (stock code 000811,).
