Reel Product Plastic Film Wrapping Machine
Reel wrapping machine is the cylindrical winding packaging machine for cylindrical objects to carry out axial packaging to achieve the overall package. The wrapper wraps reel in 360 degree and can be designed with top platen device.
Product Details
| Items | Specifications |
| Roll Diameter | 600-1500mm |
| Roll width | 500-1600mm |
| Roll Weight | Max. 2000kgs |
| Packing efficiency | 20-30 rolls/h |
| Turntable diameter | 2000mm |
| Turntable speed | 3-12rpm |
| Turntable height | 490mm/710mm |
| Machine weight | 1080kg |
| Power supply | 2.2kw, 220V, 1P, 50 Hz |
| Machine dimension | 2895(L) ×2000(W) ×2300(H) mm |
Option:
| |
Is conducive to the storage, transport and turnover of goods, with dust, moisture, cleaning the role of. Its packaging cost low, high efficiency, improve the level of packaging. At the same time, according to the actual needs of the packaging, can choose a tray. Dual purpose, automatic top out type, automatic online and other equipment.
