High cost performance stretch pallet wrapping machine
Customer infeed conveyor manipulate gadget send sign to wrapper PLC earlier than supply pallet to wrapper, and wrapper ship sign to consumer outfeed conveyor after wrapping.
Item | Specification |
Wrapping size | 500-1050mm (L) *500-1050mm (W) |
Packaging height | Max.2200mm (2400/2800mm available) |
Work efficiency | 20-40 loads/H |
Turntable speed | 0-12RPM (adjustable, soft start & stop) |
Bearing | Max. 1000kgs |
Turntable size | D=1500mm, H=78mm |
Film carriage | Driven pre-stretch carriage, move up and down on side of the tower |
Stretch ratio | Up to 1:1.2, Friction stretch |
Weight | 600kgs |
Dimension | 2745mm*1500mm*2660mm |
Film carriage on the front of the tower
Open-door pre-stretch standard film carriage. Powered pre-stretch film carriage 250% (1:3.5);
Motor: SEW brand; Motor power: 0.37kw
Film carriage lifting driving: chain driving, good stability and high reliability
