Automatic Film Pallet Carton Box Wrapping Packaging Stretch Wrapping Machine for Package
Automatic stretch pallet wrapping machines work process is using LLDPE stretch film (a plastic film) to wrap goods which load on the pallet, the stretch film provides extra support while the products being transported or stocked so that they do not tip, spill, or otherwise damage.
It is widely used in chemical industry, electronic industry, building materials, home appliances, paper making, foodstuff & drink etc, especially the container goods transportation in foreign trade.
Technical Parameter:
Model | T1650F |
Max.wrapping height | 2.4m |
Upright height | 2.8m |
Turntable loading | 2000kg |
Turntable speed | 0-15bpm/min |
Film frame up&down speed | 0-90mm/s |
Supply | 110V-220V/50-60Hz 1Phase |
Packing efficiency | 20-40packs/hour |
Gross weight | 700kg |
Machine size | L2545*W1650*H2880mm |
Package size | L2740*W1760*H980mm |
Feature:
1.Heavy load capacity
2.Variable turntable speed and film carriage up down speed
3.Manual/auto exchange
4.PLC control,wrapping cycle can setting,more economic
5.Pre stretch film carriage,more save stretch film
6.Soft start,soft stop
