Automatic Film Pallet Carton Box Wrapping Packaging Stretch Wrapping Machine for Package

Automatic stretch pallet wrapping machines work process is using LLDPE stretch film (a plastic film) to wrap goods which load on the pallet, the stretch film provides extra support while the products being transported or stocked so that they do not tip, spill, or otherwise damage.

It is widely used in chemical industry, electronic industry, building materials, home appliances, paper making, foodstuff & drink etc, especially the container goods transportation in foreign trade.


Contact Now E-Mail Telephone WhatsApp
Product Details

Technical Parameter:

ModelT1650F
Max.wrapping height          2.4m
Upright height2.8m
Turntable loading2000kg
Turntable speed0-15bpm/min
Film frame up&down speed0-90mm/s
Supply110V-220V/50-60Hz  1Phase

Packing efficiency

20-40packs/hour
Gross weight700kg
Machine sizeL2545*W1650*H2880mm
Package sizeL2740*W1760*H980mm


Packaging Stretch Wrapping Machine

Feature:

1.Heavy load capacity

2.Variable turntable speed and film carriage up down speed

3.Manual/auto exchange

4.PLC control,wrapping cycle can setting,more economic

5.Pre stretch film carriage,more save stretch film

6.Soft start,soft stop

Packaging Stretch Wrapping Machine
